Summary: Learn about five different Dinkle terminal blocks ideal for printed circuit board (PCB) applications. We offer models with 5.09 mm and 5.00 mm pitches with various locking mechanisms and flange options to suit your engineering needs.
Did you know that Imtron has access to factory stock at Dinkle, including terminal blocks? These leading-edge electronic components can be found in equipment across many different industrial sectors. Our expert team will work with you to identify the Dinkle terminal blocks that will work best for your end application.
Here’s a closer look at the Dinkle terminal blocks we have access to carry for printed circuit boards.
1. Dinkle Terminal Blocks 2EHDP PCB
Dinkle’s 2EHDP connector-socket terminal blocks are for PCB applications. The terminal block features a 5.08 mm pitch and threaded flange. The 2EHDP connectors are UL, IEC, CUL, and VDE rated or approved.
2. Dinkle 2EHDRC PCB Terminal Blocks
Dinkle’s 2EHDRC connector-socket terminal blocks are for PCB applications. The terminal block features a 5.08 mm pitch and does not lock. The 2EHDRC connectors are UL, IEC, CUL, and VDE rated or approved.
3. Dinkle 2ESDP PCB Terminal Blocks
Dinkle’s 2ESDP connector plugs are for PCB applications. The terminal block features a 5.08 mm pitch and does not lock. The 2ESDP connectors are UL, IEC, CUL, and VDE rated or approved.
4. Dinkle 2ESDV PCB Terminal Blocks
Dinkle’s 2ESDV connector plugs are for PCB applications. The terminal block features a 5.08 mm pitch and does not lock. The 2EHDRC connectors are UL, IEC, CUL, and VDE rated or approved.
5. Dinkle 5ESDV PCB Terminal Blocks
Dinkle’s 5ESDV connector plugs are for PCB applications. The terminal block features a 5.00 mm pitch and does not lock. The 5EHDRC connectors are UL, IEC, CUL, and VDE rated or approved.
Engineers fabricating printed circuit boards should consider Dinkle terminal blocks. Imtron can help interested engineers source the connector-socket and connector plugs they need. Reach out to our knowledgeable team today to source your components.
Terminal Block FAQs
What is the pitch size of the Dinkle terminal blocks Imtron carries?
The terminal blocks have either a 5.08 mm or 5.00 mm pitch, accommodating different PCB layouts and spacing requirements.
Are these terminal blocks suitable for high-voltage applications?
Yes, the featured models are UL, IEC, CUL, and VDE rated or approved, indicating their suitability for various industrial standards.
Do these terminal blocks come with locking mechanisms?
Some models, like the 2EHDP, feature threaded flanges for secure connections, while others, such as the 2EHDRC and 2ESDP, do not have locking mechanisms.
How can I purchase these terminal blocks?
Engineers can contact Imtron to source the appropriate connector-socket and connector plugs for their specific applications.
